详细参数
胶管内径 HOSE ID | 胶管外径 Hose OD | 工作压力 Working Pressure | 爆破压力 Burst Pressure | 弯曲半径 Minimum Bend Radius | 重量 Weight | |||
| Inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m |
| 1/8 | 3.3 | 8.5 | 17.2 | 2500 | 68.9 | 10000 | 13 | 0.037 |
| 3/16 | 4.8 | 10.8 | 20.7 | 3000 | 82.7 | 12000 | 20 | 0.068 |
| 1/4 | 6.4 | 13.0 | 20.7 | 3000 | 82.7 | 12000 | 33 | 0.085 |
| 5/16 | 7.9 | 15.1 | 17.2 | 2500 | 68.9 | 10000 | 46 | 0.103 |
| 3/8 | 9.5 | 17.0 | 15.5 | 2250 | 62.1 | 9000 | 51 | 0.141 |
| 1/2 | 12.7 | 20.7 | 13.8 | 2000 | 55.2 | 8000 | 76 | 0.210 |
| 3/4 | 19.0 | 27.1 | 86 | 1250 | 34.5 | 5000 | 127 | 0.287 |
| 1 | 25.4 | 34.0 | 6.9 | 1000 | 27.6 | 4000 | 203 | 0.542 |
