详细参数
胶管内径 HOSE ID | 增强层外径 Wire OD | 胶管外径 Hose OD | 工作压力 Working Pressure | 爆破压力 Burst Pressure | 弯曲半径 Minimum Bend Radius | 重量 Weight | ||||
| Inch | mm | Min(mm) | Max(mm) | mm | MPa | Psi | MPa | Psi | mm | kg/m |
| 3/8 | 9.5 | 16.9 | 18 | 21.1 | 31 | 4500 | 124 | 18000 | 127 | 0.70 |
| 1/2 | 12.7 | 19.4 | 21 | 24.3 | 28 | 4500 | 110 | 16000 | 178 | 0.83 |
| 3/4 | 19 | 26.6 | 28.2 | 31.9 | 21 | 3000 | 83 | 12000 | 241 | 1.30 |
| 1 | 25.4 | 34.5 | 36.1 | 40.5 | 21 | 3000 | 83 | 12000 | 305 | 1.70 |
| 1 1/4 | 31.8 | 43.3 | 45.6 | 50.7 | 17 | 2500 | 69 | 10000 | 419 | 3.08 |
| 1 1/2 | 38.1 | 49.6 | 52 | 58.7 | 14 | 2000 | 55 | 8000 | 508 | 4.30 |
| 2 | 50.8 | 63.9 | 66.2 | 73 | 14 | 2000 | 55 | 8000 | 660 | 5.63 |
