详细参数
通径 DN | 胶管内径 HOSE ID | 增强层外径 Wire OD | 胶管外径 Hose OD | 工作压力 Working Pressure | 爆破压力 Burst Pressure | 弯曲半径 Minimum Bend Radius | 重量 Weight | |||
| Inch | mm | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m | |
| 10 | 3/8 | 9.5 | 17.5 | 21.4 | 44.5 | 6450 | 180 | 26000 | 180 | 0.78 |
| 13 | 1/2 | 12.7 | 20.2 | 24.0 | 41.5 | 6000 | 166 | 24000 | 230 | 0.89 |
| 16 | 5/8 | 15.9 | 23.8 | 28.2 | 35.0 | 5000 | 140 | 20000 | 250 | 1.11 |
| 19 | 3/4 | 19.0 | 28.2 | 32.2 | 35.0 | 5000 | 140 | 20000 | 300 | 1.59 |
| 25 | 1 | 25.4 | 35.5 | 39.7 | 28.0 | 4000 | 112 | 16000 | 340 | 2.02 |
| 32 | 1-1/4 | 31.8 | 46.0 | 50.8 | 21.0 | 3000 | 84 | 12000 | 460 | 3.32 |
| 38 | 1-1/2 | 38.1 | 52.4 | 57.7 | 18.5 | 2700 | 74 | 10800 | 560 | 3.7 |
| 51 | 2 | 50.8 | 65.3 | 69.6 | 16.5 | 2400 | 66 | 9600 | 660 | 5.47 |
