详细参数
通径 DN | 胶管内径 HOSE ID | 胶管外径 Hose OD | 工作压力 Working Pressure | 爆破压力 Burst Pressure | 弯曲半径 Minimum Bend Radius | 重量 Weight | |||
| Inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m | |
| 6 | 1/4 | 6.4 | 13.4 | 34.5 | 5000 | 138 | 20000 | 50 | 0.27 |
| 8 | 5/16 | 7.9 | 15.0 | 29.3 | 4250 | 117 | 17000 | 55 | 0.35 |
| 10 | 3/8 | 9.5 | 17.4 | 27.5 | 4000 | 110 | 16000 | 65 | 0.42 |
| 13 | 1/2 | 12.7 | 20.6 | 24.0 | 3500 | 96 | 14000 | 90 | 0.52 |
| 16 | 5/8 | 15.9 | 23.8 | 19.0 | 2750 | 76 | 11000 | 100 | 0.63 |
| 19 | 3/4 | 19.0 | 27.8 | 15.5 | 2250 | 62 | 9000 | 120 | 0.81 |
| 25 | 1 | 25.4 | 35.9 | 13.8 | 2000 | 55 | 8000 | 150 | 1.17 |
| 32 | 1-1/4 | 31.8 | 43.6 | 11.2 | 1625 | 45 | 6500 | 210 | 1.49 |
